Specifications:

• Display
• Screen Size23.8 inch
• Active Display Area527.04 (H) mm × 296.46 (V) mm
• Resolution1920 × 1080
• BacklightE-LED
• Pixel Pitch0.2745 (H) mm × 0.2745 (V) mm
• Brightness250 cd/m²
• Viewing Angle178° (H) / 178° (V)
• Color Depth16.78 M
• Contrast Ratio1000 : 1
• Response Time14ms
• Refresh RateTyp. 60 Hz , Max. 100Hz
• HazeHaze 25%，3H
• Reliability7 × 24 H
• Color Gamut72% NTSC

• Interface
• Video & Audio InputHDMI 1.4 × 1, VGA × 1
• Video & Audio OutputAudio Out × 1
• Data Transmission InterfaceNone
• Control InterfaceNone

• Power
• Power SupplyDC 12V, 2.0A
• Power Consumption≤ 24 W
• Standby Consumption≤ 0.5 W

• Working Environment
• Working Temperature0℃ to 40 ℃ (32 ℉ to 104 ℉)
• Working Humidity20% to 90% RH (Non-Condensing)
• Storage Temperature-20 ℃ to 60 ℃ (-4 ℉ to 140 ℉)
• Storage Humidity10% to 90% RH (Non-Condensing)

• General
• Casing MaterialPlastic
• VESA75 mm × 75 mm (4 - M4 × 6 mm)
• Bezel Width2.0 mm (top/left/right), 23.55 mm (bottom)
• Product Dimensions (W × H × D)

  With base: 539.7 (W) mm × 427.33 (H) mm × 185.69(D) mm

  21.25 (W) inch × 16.82 (H) inch × 7.31 (D) inch

  Without base: 539.7 (W) mm × 327.33 (H) mm × 43.5 (D) mm

  21.25 (W) inch × 12.89 (H) inch × 1.71 (D) inch

• Package Dimensions (W × H × D)

  611 (W) mm × 405 (H) mm × 118 (D) mm

  (24.06(W) × 15.94(H) × 4.65 (D) ) inch

• Net Weight2.85 ± 0.5 kg
• Gross Weight3.85± 0.5 kg
• Packing ListMonitor × 1, Base component × 1, Power adapter (12 V, 2 A) × 1, HDMI cable (1.5 m) × 1, User manual × 1, Multilingual manual × 1
• Remarks

  The base is included by default.

  The product appearance and parameters in this specification may vary from your actual device. Please consult our local sales staff for further information
