Specifications:

• Lens
• Lens Type

  2.8 to 12 mm

  8 to 32 mm

• Aperture

  2.8 to 12 mm: F1.2 to F2.5t

  8 to 32 mm: F1.7 to F1.73

• Focal Length & FoV

  2.8 to 12 mm, horizontal FoV: 114.5° to 41.8°, vertical FoV: 59.3° to 23.6°, diagonal FoV: 141.1° to 48°,

  8 to 32 mm, horizontal FoV: 42.5° to 15.1°, vertical FoV: 23.3° to 8.64°, diagonal FoV: 49.6° to 17.3°

• FocusAuto，Vari-focal lens, motor-driven lens

• Supplement Light
• Supplement Light TypeIR Light, Warm White Light
• Supplement Light Range

  Video:

  2.8 mm to 12 mm: 25 m

  8 mm to 32 mm: 50 m

  Vehicle License Plate:

  2.8 mm to 12 mm: 10 m

  8 mm to 32 mm: 20 m

• IR WavelengthWarm White Light 3000 K, IR Light 850 nm

• Capture Mode
• Trigger TypeVideo Detection, I/O Coil, Radar Mixed Traffic
• Picture TypeScene Picture, Scene Picture + Close-up Picture
• Scene ModeEntrance & Exit Toll Gate, Underground Parking Entrance & Exit
• Capture TypeStrobe Light Mode

• Capture Parameters
• Image FormatJPEG
• Capture Resolution2688 × 1520
• License Plate RecognitionForward, Backward, Bidirection
• LED ControlSupports automatic light control/time control of LEDs
• Smart RecognitionANPR, Motor Vehicle Feature, Vehicle Color Recognition, Enable Vehicle Manufacturer Recognition
• Capture Picture OverlayLocation, Capture Time, Plate Number, Capture No., Vehicle Color Vehicle Type

• Image
• WDR140 dB
• Main Stream

  50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

  60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

• Sub-Stream

  50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)

  60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)

• Image Settings

  Saturation: 0 to 100

  Brightness: 0 to 100

  Contrast: 0 to 100

  Gain: 0 to 100

  3D DNR: Off, Normal, and Expert modes are selectable.

  White balance: White Balance 1 and White Balance 2 are selectable.

• Image Parameters SwitchYes
• WDR SwitchOn, Time, Brightness
• Frame Rate25 fps (P)/30 fps (N)

• Entrance and Exit
• Barrier Gate Control ModeBy Camera/Platform/Mixed
• Keep Boom Pole Open for Following VehicleEnable/Disable
• Lock Barrier Gate for Large-Sized VehicleYes
• Relay Output2-ch relay output, supporting opening and closing of barrier gates
• Barrier Gate StatusNone, Barrier Gate Close In Place, Barrier Gate Open In Place, Remote Control Open In Place
• Allowlist and BlocklistUp to 100,000 allowlist and blocklist totally

• Video
• ROI8 regions respectively for main stream and sub-stream, 6 levels for each region.
• Video Compression

  Main stream: H.265/H.264/MJPEG,

  Sub-stream: H.265/H.264/MJPEG,

• H.264 Type

  Low profile

  Medium profile

  High Profile

• Video Bit Rate32 Kbps to 16 Mbps
• Bit Rate TypeConstant, Variable
• Scalable Video Coding (SVC)H.265 and H.264 encoding

• Network
• Network StorageNAS (NFS, SMB/CIFS), auto network replenishment (ANR) together with high-end Hikvision memory card, memory card encryption and health detection are supported.
• ProtocolTCP/IP, ICMP, HTTP, HTTPS, FTP Upload Picture, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, SNMP, IGMP, QoS, IPv6, UDP, SSL/TLS, WebSocket
• APIOpen Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP, Otap, Guarding Vision Platform
• ClientHik-Connect, Hik-Central，SDKdemo，PMS
• Web BrowserPlug-in required live view: IE10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local service: Chrome 41.0+, Firefox 30.0+
• SecurityPassword protection, complicated password, HTTPS encryption, watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2

• Camera
• Max. Resolution2688 × 1520
• Sensor Type1/1.8" Progressive Scan CMOS
• Min. Illumination

  Color: 0.0005 Lux @ (F1.2, AGC ON)

  B/W: 0.0001 Lux @ (F1.2, AGC ON)

  0 Lux with IR

• Shutter1/30 s to 1/100,000 s
• Day/Night SwitchSupported
• IR Cut Filter

  IR cut filter

  Blue glass module to reduce ghost phenomenon

• Interface
• Audio1 input (line in), 1 output (line out)
• Alarm Input3-ch triggered inputs
• Alarm Output1-ch alarm output
• WiegandSupported: CardID 26bit, SHA-1 26bit, Hik 34bit, NEWG 72bit
• RS-2321-ch RS-485 serial port
• RS-4851-ch RS-232 serial port
• Network Interface1 RJ45 10M/100M self-adaptive Ethernet port
• Memory Card Slot1 TF card slot, up to 1 TB

• Smart Function
• LPR Accuracy

  Accuracy (Under recommended installation and lighting conditions):

  License plate recognition rate ≥98.5%

  Capture rate ≥99%

  Driving direction accuracy rate ≥98%

• Vehicle Type RecognitionCar/Van/Bus/Truck/Light Truck/SUV_MPV/Pickup/Pedestrian/Motorcycle/Tricycle
• Vehicle ColorRed, Yellow (including orange, golden), Green, Cyan, Blue, Purple, Pink, Brown, White, Gray (including silver), Black
• Vehicle Brand84 manufacturers: Hyundai, Toyota, KIA, Honda, Volkswagen, Benz, Nissan, Ford, Isuzu, BMW, Chevrolet, Mitsubishi, Renault, Opel, Suzuki, Skoda, Daewoo, Audi, Mazda, GAC HINO, Peugeot, SsangYong, Citroen, Fiat, Scania, MAN, Volvo, Lexus, Seat, Land Rover, Daihatsu, Dongwo, Subaru, Iveco, MINI, JEEP, Porsche, Chery, Dodge, Chrysler, Acura, Alfa Romeo, Great Wall, Infiniti, Smart, Saic Maxus, JAC, Jaguar, GMC, Lincoln, JMC, SAAB, FAW, Yutong, Guangzhou Yunbao, Joylong, Geely, Cadillac, JBC, An‘kai, Haima, Foton, King Long, Dongfeng, Geely-Emgrand, Perodua, UD, BYD, Renault Samsung, Proton, HICOM, Malaysia_Unknown 1, Hyundai-Rohens, SsangYong-Old Version, Equus-Old Version, CNHTC, Rolls-Royce, Beiben Truck, Haval, Hino, Kia-Borrego, Chang‘an, Alfa, FORO
• ANPR Supported Country/Region

  6 areas ( Asia, Africa, America, Europe, Oceania, Russian-Speaking Regions) and more than 130+ countries/regions （Statistical quantity includes baseline version and customized version.）

  Asia:

  Hong Kong( China), Macau( China), Taiwan( China), Japan, South Korea, Mongolia, Indonesia, Myanmar, Vietnam, the Philippines, Thailand, Laos, Cambodia, Malaysia, Singapore, Pakistan, Sri Lanka, Nepal, India, Bangladesh, Qatar, Kuwait, Oman, Saudi Arabia, Bahrain, Lebanon, Jordan, Iraq, United Arab Emirates, Dubai, Fujairah, Al Ain, Abu Dhabi, Ajman, Sharjah, Umm Al Qwain, Yemen

  Africa:

  Egypt, Libya, Tunisia, Algeria, Morocco, Nigeria, Senegal, Ivory Coast, Ghana, Kenya, Tanzania, Uganda, Ethiopia, South Africa, Namibia, Zimbabwe, Zambia, Cameroon, Angola, Mauritius, Sierra Leone

  America:

  Canada, Mexico, Panama, Costa Rica, El Salvador, Guatemala, Trinidad and Tobago, Dominican Republic, Argentina, Brazil, Chile, Colombia, Peru, Ecuador, Paraguay, Uruguay, Bolivia, Venezuela, Suriname

  Europe:

  Italy, Spain, Portugal, Greece, Croatia, Slovenia, Montenegro, Albania, the Republic of North Macedonia, Serbia, Bosnia and Herzegovina, Bulgaria, Romania, Malta, San Marino, Andorra, Germany, Poland, Czech Republic, Slovakia, Hungary, Austria, Switzerland, Liechtenstein, France, the UK, Ireland, Netherlands, Belgium, Luxembourg, Sweden, Denmark, Finland, Iceland, Lithuania, Israel, Palestine, Kosovo, Cyprus, Turkey

  Oceania: Australia, New Zealand

  Russian-Speaking Regions:

  Kazakhstan, Uzbekistan, Kyrgyzstan, Tajikistan, Azerbaijan, Georgia, Estonia, Latvia, Russia, Ukraine, Moldova, Armenia, Turkmenistan, Belarus

• Approval
• EMC

  CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EEN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014);

  KC (KN 32: 2015, KN 35: 2015)

• Security

  CB (IEC 62368-1: 2014 + A11);

  CE-LVD (EN 62368-1: 2014/A11: 2017);

  BIS (IS 13252 (Part 1): 2010/IEC 60950-1: 2005);

• EnvironmentCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
• ProtectionIK10 (IEC 62262: 2002), IP67 (IEC 60529-2013)

• General
• Power Supply12 to 24 VDC/PoE (802.3af, 44 V to 57 V), 300 mA to 230 mA
• Working Consumption10 W Max.
• Dimensions415 mm × 145 mm × 145 mm (16.34 × 5.71 × 5.71 inch)
• 3.25 kg (7.17 lb.)
• Weight (with Package)4.3 kg (9.48 lb.)
• Package Size465 mm × 200 mm × 198 mm (18.31 × 7.87 × 7.80 inch)
• Storage Conditions

  Temperature: -20 °C to 70 °C (- 4°F to 158 °F)

  Humidity: 95% (non-condensing)

• Startup and Operating Conditions

  Temperature: -30 °C to 70 °C (-22 °F to 158 °F)

  Humidity: 95% (non-condensing)

• Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
