Specifications:

• General
• Product Dimension (W × H × D)111mm×56mm×47.7mm
• Package Dimension (W × H × D)148mm×98mm×72mm
• Net Weight0.221 kg
• Packing List

  WiFi Extender× 1

  Quick Start Guide × 1

  Regulatory Compliance and Safety Information × 1

• Packing MethodSingle pack
• Working Temperature0 ℃ to 40 ℃ (32 ℉ to 104 ℉)
• Working Humidity10% to 90% RH non-condensing
• Storage Temperature-40 ℃ to 70 ℃ (-40 ℉ to 158 ℉)
• Storage Humidity10% to 90% RH non-condensing
• Max. Power Consumption≤ 3.8 W
• Gross Weight0.192 kg

• Wireless Parameter
• Data Rate

  ≤ 300 Mbps

  2.4 GHz: 300 Mbps

• Wireless StandardIEEE802.11b,IEEE 802.11g, IEEE 802.11n @2.4GHz
• Working Frequency Band2.4 GHz
• Transmitting Power<20dBm
• Wireless Performance2*2 MIMO supported
• Receiving Sensitivity

  2.4 GHz

  11b-1M:-96dBm

  11g-54M:-77dBm

  11n-20M-MCS7:-75dBm

  11n-40M-MCS7:-73dBm

• Antenna2*3dBi external antennas

• Hardware Parameter
• LED Indicator1 * Signal/Power/WPS LED
• Reset

  1 * WPS Button

  1 * Reset Button

• Power Supply Method100-240V ~50/60HZ 0.3A

• Software Function
• Application functionRepeater Mode
• Security Mode

  Default encryption mode: Mix WPA-PSK/WPA2-PSK

  WPA algorithm: TKIP

• Security MechanismHide SSID
• Management MethodWeb
• UpgradeWeb
• System LogFirmware upgrade, Restore factory settings, Login password, and Reboot
